  • Normal
    pipe
    size    		 Outside
    dia. of
    Bridas    		 Minimum
    thickness
    of Bridas    		 Overall          Length Bolt
    Circle    		 No. and
    Size of
    Holes    		 O.D. of
    raised
    face
    Welding
    neck    		 Slip-on
    &
    socket
    welding    		 Lap
    Joint
    		O Q Y Diam. No. dia. R
    1/2 133.4 30.2 73.0 39.7 39.7 88.9 4 22 34.9
    3/4 139.7 31.8 79.4 42.9 42.9 95.3 4 22 42.9
    1 158.8 34.9 88.9 47.6 47.6 108.0 4 25 50.8
    1-1/4 184.2 38.1 95.3 52.4 52.4 130.2 4 29 63.5
    1-1/2 203.2 44.5 111.1 60.3 60.3 146.0 4 32 73.0
    2 235.0 50.8 127.0 69.9 69.9 171.5 8 29 92.1
    2-1/2 266.7 57.2 142.9 79.4 79.4 196.9 8 32 104.8
    3 304.8 66.7 168.3 92.1 92.1 228.6 8 35 127.0
    3-1/2
    4 355.6 76.2 190.5 108.0 108.0 273.0 8 41 157.2
    5 419.1 92.1 228.6 130.2 130.2 323.9 8 48 185.7
    6 482.6 108.0 273.1 152.4 152.4 268.3 8 54 215.9
    8 552.5 127.0 317.5 177.8 177.8 438.2 12 54 269.9
    10 673.1 165.1 419.1 228.6 228.6 539.8 12 67 323.9
    12 762.0 184.2 463.6 254.0 254.0 619.1 12 73 381.03
    14 --- --- --- --- --- --- -- --- ---
    16 --- --- --- --- --- --- -- --- ---
    18 --- --- --- --- --- --- -- --- --
    20 --- --- --- --- --- --- -- --- --
    24 --- --- --- --- --- --- -- --- --
