  • Pipe Bridas Neck Raised Bolts Weight of
    one Bridas
    7.85 kg/dm3)
    kg
    NW d1 D b k h1 d3 s r h2 d4 f No. Thread d2
    10 14 90 16 60 35 25 1.8 4 6 40 2 4 M12 (1/2") 14 0.661
    17.2 28
    15 20 95 16 65 38 30 2 4 6 45 2
    		0.746
    21.3 32
    20 25 105 18 75 40 38 2.3 4 6 58 2
    		106
    26.9 40
    25 30 115 18 85 40 42 2.6 4 6 68 2
    		1.29
    33.7 46
    32 38 140 18 100 42 52 2.6 6 6 78 2
    		1.88
    42.4 56
    40 44.5 150 18 110 45 60 2.6 6 7 88 3
    		2.33
    48.3 64
    50 57 165 20 125 48 72 2.9 6 8 102 3
    		M16 (5/8") 18 2.82
    60.3 75
    65 76.1 185 22 145 52 90 2.9 6 10 122 3
    		3.74
    80 88.9 200 24 160 58 105 3.2 8 12 138 3
    		4.75
    100 108 235 24 190 65 128 3.6 8 12 138 3 8 M20 (3/4") 23 6.52
    114.3 134
    125 133 270 26 220 68 155 4 8 12 188 3 8 M24 (7/8") 27 9.07
    139.7 162
    150 159 300 28 250 75 182 4.5 10 12 188 3
    		M24 (7/8")
    		11.8
    168.3 192
    175 191 350 32 295 82 215 5.6 10 16 285 3 12 M27 (1") 30 18.2
    193.7 218
    200 216 375 34 320 88 240 6.3 10 16 285 3
    		21.5
    219.1 244
    250 267 450 38 385 105 298 7.1 12 18 345 3
    		34.9
    273 306
    300 318 515 42 450 115 352 8 12 18 410 4 16 M30 (1-1/8") 33 49.7
    323.9 362
    350 355.6 580 46 510 125 408 8.8 12 20 460 4
    		M33 (1-1/4") 36
    368 68.1
    400 406.4 660 50 585 135 462 11 12 20 535 4
    		M36 (1-3/8") 39
    419 96.5
    500 508 755 52 670 140 562 14.2 12 20 615 4 20 M39 (1-1/2") 42
    521 117
