Datos técnicos

Bridas 150Lb Dimensiones | Bridas 300Lb Dimensiones | Bridas 600Lb Dimensiones | Bridas 900Lb Dimensiones | Bridas 1500Lb Dimensiones | Bridas 2500Lb Dimensiones | SOLDADURA NECK BRIDAS | DIN 2527 Bridas | DIN 2576 Bridas | DIN 2632 Bridas | DIN 2633 Bridas | DIN 2634 Bridas | DIN 2635 Bridas | DIN 2642 Bridas


  • Pipe Bridas
    		Bolts Weight of
    one Bridas
    7.85 kg/
    dm3) kg
    NW d1 ds D b1 k Number Thread d2
    10 14
    17.2)     		14.5
    17.7     		90 14 60 4 M12 (1/2") 14 0.613
    0.605
    15 20
    21.3)     		20.5
    21.8     		95 14 65 4 M12 (1/2") 14 0675
    0.669
    20 25
    26.9)     		25.5
    27.4     		105 16 75 4 M12 (1/2") 14 0.947
    0.936
    25 30
    33.7)     		30.5
    34.2     		115 16 85 4 M12 (1/2") 14 1.14
    1.11
    32 38
    42.4)    		 38.5
    42.9     		140 16 100 4 M16 (5/8") 18 1.66
    1.62
    40 44.5
    48.3)     		45
    48.8     		150 16 110 4 M16 (5/8") 18 1.89
    1.86
    50 57
    60.3)     		57.5
    60.8     		165 18 125 4 M16 (5/8") 18 2.51
    2.47
    65 76.1) 76.6 185 18 145 4 M16 (5/8") 18 3.00
    80 88.9) 89.4 200 20 160 4 M16 (5/8") 18 3.79
    100 108
    114.3)     		108.5
    114.8     		220 20 180 8 M16 (5/8") 18 4.20
    4.03
    125 133
    139.7)     		133.5
    140.2     		250 22 210 8 M16 (5/8") 18 5.71
    5.46
    150 159
    168.3)     		159.5
    168.8     		285 22 210 8 M16 (3/4") 23 6.72
    6.57
    175 191
    193.7)     		192
    194.7     		315 24 270 8 M20 (3/4") 23 8.60
    8.45
    200 216
    219.1)     		216
    220.1    		 340 24 295 8 M20 (3/4") 23 9.50
    9.31
    250 267
    273)     		268
    274     		395 26 350 12 M20 (3/4") 23 12.5
    11.9
    400 406.4
    419     		407.4
    420     		565 32 515 16 M24 (7/8") 27 27.9
    25.9
    500 508)
    521     		509
    522     		670 38 620 20 M24 (7/8") 27 37.9
    41.1
